Kubey Stalker Knife Orange G10, Satin D2 by Johan Jordaan (KU504B)
- Stalker Orange G10, a compact EDC folding knife with a satin finish, designed by Johan Jordaan. The Drop Point blade is made of D2 tool steel, and the handle is made of durable G10 composite. Two opening mechanisms and an intuitive Crossbar Lock.
40,73 €Kubey Stalker Orange G10 Folding Knife, Satin D2 by Johan Jordaan (KU504B)
The Kubey Stalker KU504B is a lightweight EDC folder designed by Johan Jordaan, featuring an orange G10 handle and a D2 steel blade. The Crossbar Lock, phosphor bronze washers, thumb studs on both sides, and a hole in the blade make for a functional set for everyday use.
The 78.00 mm blade features a Drop Point profile, a flat grind, and a satin finish. The orange G10 gives this version a distinctive look and makes it easy to spot the knife among your gear.
D2 Steel and Vacuum Hardening
The blade is made of D2 steel, hardened to 59–61 HRC. Vacuum hardening helps achieve high wear resistance and stable steel properties.
Drop Point, flat grind, and satin
The Drop Point profile offers versatile performance, and the flat grind works well for a wide range of cutting tasks. The satin finish gives the blade a classic look.
Orange G10, Crossbar Lock, and phosphor bronze washers
The handle is made of orange G10. The construction is complemented by gray stainless steel spacer sleeves and sandblasted steel structural components.
The pivot operates on phosphor bronze washers, while the Crossbar Lock stabilizes the blade when open. The clip can be moved to the right or left side in the tip-up configuration.
Key Features at a Glance
- D2 – steel with a hardness of 59–61 HRC.
- Vacuum hardening – enhances the steel’s durability and stability.
- Drop Point – a versatile blade profile.
- Flat grind – functional working geometry.
- Satin – satin finish on the blade.
- Orange G10 – orange handle.
- Crossbar Lock – lock with a crossbar locking element.
- Phosphor Bronze Washers – pivot mounted on phosphor bronze washers.
- Thumb Studs and Thumb Hole – two ways to open the knife manually.
- Reversible clip – mounts on the right or left side.
Technical Data
| Product Number | KU504B |
| Product Name | Kubey Stalker Orange G10, Satin D2 by Johan Jordaan |
| Overall Length | 183.00 mm / 7.20" |
| Blade Length | 78.00 mm / 3.07" |
| Blade Thickness | 3.10 mm / 0.12“ |
| Handle Length | 105.00 mm / 4.13” |
| Handle Thickness | 12.00 mm / 0.47" |
| Weight | 82.00 g / 2.89 oz |
| Blade Material | D2 |
| Blade hardness (HRC) | 59–61 HRC |
| Blade grind | Flat |
| Blade finish | Satin |
| Handle material | G10 |
| Handle finish color | Orange |
| Backspacer material | Stainless Steel (spacer sleeves) |
| Backspacer Color | Gray |
| Clip | Right/Left, tip-up |
| Clip material | Stainless Steel |
| Pivot pin | Phosphor Bronze Washers |
| Lock | Crossbar Lock |
| Opening mechanism | Manual, Thumb Studs / Thumb Hole |
| Additional accessories | None |
| Designer | Johan Jordaan |
| Brand | Kubey |
| Manufacturer | Kubey Knife |
| Country of origin | P.R.C. |
Frequently Asked Questions
How do I care for D2 steel?
After use, it’s a good idea to thoroughly clean and dry the blade. Periodically applying a thin layer of protective coating to the surface helps reduce the risk of corrosion.
How do I sharpen the Kubey Stalker?
D2 works well with ceramic and diamond sharpeners, as well as guided sharpening systems. It’s best to regularly refresh the edge before it becomes significantly dull.
What sharpening angle should be used for the Kubey Stalker?
The recommended sharpening angle range is 15°–20°. This allows you to adjust the edge geometry to your preferred balance between durability and cutting performance.
How does the Crossbar Lock work?
The Crossbar Lock locks the blade in place using a crossbar. The design allows for convenient operation from both sides of the handle.
How do you maintain the pivot on phosphor bronze washers?
Keep the pivot clean and regularly remove dust and fine debris from around it. If necessary, you can use a small amount of a suitable lubricant.
Prepared by: Specialists at Sharg® company – Your expert in EDC and cutting tools
